Coaxial sockets are also referred to as tips or barrel sockets. They have primarily been used to connect two cables and connect the devices to external power supplies. They are also used to establish a connection between two cables while maintaining the shielding off external interference. Coaxial sockets are also available in a variety of sizes to suit the dimensions of different wires. Each of these coaxial socket works in combination to ensure smooth signal transmission. Some of the coaxial sockets also include switches that allow the internal batteries to be disconnected if any external power supply is connected to the socket.
Types of coaxial sockets
Coaxial sockets are used for a wide variety of purposes. This is the reason why the sockets of coaxial sockets are also available in a variety of designs. Each of the coaxial sockets is specifically designed to work seamlessly with the most cable and function under harsh conditions. Coaxial sockets must be able to resist stressors like high pressure, impact, vibration, and high temperature.
Coaxial sockets are also made for radio frequency transmission. These types of coaxial sockets need a particular kind of sockets that provide constant electrical resistance at the point where the connection between the two cables has been established. These sockets are pretty delicate and can quickly get damaged.
Types of coaxial sockets
7/16 din connector
These coaxial sockets are mainly used for connecting coaxial cables in environments that are exposed two dust and moisture. Such coaxial sockets are most commonly used in the case of broadcasting equipment and radio base stations.
BNC sockets or coaxial sockets are mainly used in the case of television, AV equipment, test instruments, and radio. They are primarily designed for rapid connection and rapid disconnection.
Also referred to as the F-type sockets or coaxial sockets, these are mainly used to bring an electrical signal to the TV set. These can be paired with RG59 cables and RG6 cables.
These sockets are most commonly used with mobile equipment and are miniature threaded sockets.
MBX sockets are responsible for establishing connections within the equipment which works on radio frequency. The primary features of these sockets are that they are highly robust they offer excellent electrical performance and power handling.
If you want to purchase a coaxial socket, check out the TTS group. They have been providing test tooling solutions since 1979 to their clients.
Finding the correct type of coaxial socket
When you go to purchase a coaxial socket, you need to keep in mind certain vital parameters of the cable that you plan to connect. These key parameters include
- The environment
- The voltage
- The frequency that you need
- Whether a male or female connection is needed
These factors will play a crucial role in determining the type of coaxial socket you buy. The male coaxial sockets have protruding pins, while the female sockets have a recess to receive the pin.
